Type: | PISTON | Configuration:: | Portable |
---|---|---|---|
Power Source: | AC Power, Diesel Engine | Lubrication Style: | Lubricant |
Place Of Origin: | Zhejiang Of China | Brand Name: | Kaishan |
Highlight: | diesel driven air compressor,lubricated air compressor |
Huge piston mining air compressor belt driven 105CFM 580PSI 30HP 40bar 22kw CVFY 13 7
Introduction about piston diesel air compressor for mining:
Our Mining diesel Driven Small and Huge Piston Air Compressor are mainly used to supply stable and clean compressed air to the pneumatic tools and keep them working smoothly and efficiently.
1. Strongly power-driven and big air end with design, the air compressor owns bigger and heavier main parts thanother products in the same trade with better selection andsufficient using of materials especially with main fittings. In addition, it is more suitable for be applied in the continuous operation under heavy load for long working time with
higher reliability and longer lifespan.
2. special designed is made in heat emission and air flow, which leads to low air output temperature and low possiblity of carbon deposit.
3. the piston ring imported from Japan is introduced in designing pistol ring, which is durable and sealable.
4. some relevant working units are received precision balance, which makes it more stable with lower noise
5. the core of air filter is made of imported filter paper, which acts well in filtering and absorbing noise.
KAISHAN Machinery is the leading manufacturer of portable compressed air machines in the world.Used in a wide variety of industries,
Model No. |
VF13/7 |
VF13/7 |
Style |
PORTABLE, piston, electricdriven |
PORTABLE, piston, diesel driven |
Driven by |
75KW electric engine |
Yuchai 6108 diesel engine |
connect |
gear wheel |
gear wheel |
Rotation speed R/min |
980 |
1050 |
Air capacity |
13m3/min(458cfm) |
13m3/min(458cfm) |
Air pressure |
0.7Mpa(100psi) |
0.7Mpa(100psi) |
Lubricate by |
splash and oil lubrication |
splash and oil lubrication |
Package |
Naked or others |
Naked or others |
Specifications:
|
Air Delivery |
Exhaust Pressure |
Engine |
Weight |
VF-3/7 |
3.0 |
0.7 |
Y200L1-6 DianJi(18.5Kw) |
900 |
VF-6/7 |
6.0 |
0.7 |
Y250M-6 DianJi(37Kw) |
1250 |
VF-7/7 |
7.0 |
0.7 |
Y160M-6 DianJi(40Kw) |
1300 |
CVF-7/7 |
7.0 |
0.7 |
YuChai 4108G ChaiYouJi |
1550 |
CVFY-7/7 |
7.0 |
0.7 |
YuChai 4108G ChaiYouJi |
2050 |
VF-9/7 |
9.0 |
0.7 |
Y280M-6 DianJi(55Kw) |
1700 |
VF-10/7 |
10.0 |
0.7 |
Y280M-6 DianJi(65Kw) |
1750 |
CVFY-10/7 |
10.0 |
0.7 |
YC4108ZG |
2900 |
VF-13/7 |
13.0 |
0.7 |
Y280M-6DianJi(75Kw) |
1800 |
CVFY-13/7 |
13.0 |
0.7 |
YC6108ZG |
2900 |
CVFY-13/7 |
13.0 |
0.7 |
Commins 6BT5.9-C118 |
2700 |
Competitive Advantage:
1. Heavy duty roller bearing - Oversize crankshaft roller bearings handling high compression load and precision balanced overhung crankshaft for smooth continuous operation
2. Precision cast iron cylinders - Separately cast cylinders with radial fins remove heat efficiently are precision honed for compatibility with piston rings
3. Solid piece connecting rods - Solid end precision connecting rod without bolts and nuts come loose
4. High flow valves assembly - Improved heat treated stainless steel valves assembly increase flow area for durable, reliable operation and easy removal service
5. Heavy duty discharge checkvalves - Patient "Spring-Cushion" design high pressure gas check valves for quiet and lasting operation
6. Filled syntehtic lubricant - Improved performance and increase compressor's life span withstand higher operating temperature, eliminates carbon build-up and extend lubricants change period
7. Efficient motor - Totally enclosed fan cool(TEFC) squirrel cage induction Class F insulation, IEC frame electric motor
8. Safety Valve Protection - Inter-stage and discharge safety valves protected system overpressures
9. Inter and after cooler - High efficient and maintenance free finned tube air cooled after-cooler lower compressed air discharge temperature
10. Easy access cast iron crankcase - Front access heavy duty cas iron crankcase for easy inspection and maintenance allow total oil slag removal
cooperation terms:
1) Delivery time :within 30days after receiving your advance payment
2) Payment terms:T/T 50% in advance ,the balance should be paid within 5days against the B/L date
3) Package:1,plywood cases suitable for sea transportation 2,Fumigation-free wooden cases 3,simple package
4) Air compressor HS CODE:8414809090
5) Quality Guarantee:12 months from delivery date(quick-wear part except)
6) After-sale service:For warranty repair/ replacement, user should send defective items back then supplier re-supply the same to user whin assurance period for free(user in charge of freight fee
