Product Details:
Payment & Shipping Terms:
|
| Type: | Vertical Type Or Horizontal Type | Name: | Air Tank |
|---|---|---|---|
| Usage: | Air, Nitrogen Or Vacuo | Pressure: | 10 Bar, 20 Bar, 30 Bar, 40 Bar |
| Volume: | 0.3m3, 0.6m3, 1m3, 1.5m3...10m3 | Condition: | New |
| Warranty: | 10 Years | ||
| Highlight: | 1.3mpa Air Compressor Reservoir Tank,1000L Air Compressor Reservoir Tank,Silk air compressor expansion tank |
||
1. Types: storage tank, air storage tank, vertical storage tank, horizontal storage tank, stainless steel storage tank and so on.
2. Materials: stainless steel,
Technical parameters of Pressure Vessel Series
| Model | Volume (m3) |
Working pressure (bar) |
Total Height (mm) |
Inside diameter (mm) |
Net weight (KG) |
| 0.3/8 | 0.3 | 8 | 1560 | 550 | 92 |
| 0.3/10 | 10 | 1562 | 112 | ||
| 0.3/13 | 13 | 1564 | 168 | ||
| 0.3/16 | 16 | 1564 | 156 | ||
| 0.3/25 | 25 | 1568 | 195 | ||
| 0.3/30 | 30 | 1568 | 195 | ||
| 0.3/40 | 40 | 1572 | 262 | ||
| 0.5/8 | 0.5 | 8 | 2063 | 600 | 655 |
| 0.5/10 | 10 | 2063 | 655 | ||
| 0.5/13 | 13 | 2067 | 657 | ||
| 0.5/16 | 16 | 2067 | 657 | ||
| 0.6/8 | 0.6 | 8 | 1844 | 700 | 170 |
| 0.6/10 | 10 | 1846 | 196 | ||
| 0.6/13 | 13 | 1846 | 305 | ||
| 0.6/16 | 16 | 1846 | 240 | ||
| 0.6/25 | 25 | 1850 | 280 | ||
| 0.6/30 | 30 | 1855 | 372 | ||
| 0.6/40 | 40 | 1859 | 410 | ||
| 1.0/8 | 1.0 | 8 | 2240 | 800 | 226 |
| 1.0/10 | 10 | 2242 | 262 | ||
| 1.0/13 | 13 | 2340 | 271 | ||
| 1.0/16 | 16 | 2343 | 325 | ||
| 1.0/25 | 25 | 2351 | 490 | ||
| 1.0/30 | 30 | 2355 | 576 | ||
| 1.0/40 | 40 | 2355 | 582 | ||
| 1.5/8 | 1.5 | 8 | 2357 | 1000 | 338 |
| 1.5/10 | 10 | 2357 | 338 | ||
| 1.5/13 | 13 | 2359 | 388 | ||
| 1.5/16 | 16 | 2363 | 498 | ||
| 1.5/25 | 25 | 2368 | 630 | ||
| 1.5/30 | 30 | 2372 | 735 | ||
| 1.5/40 | 40 | 2380 | 1050 | ||
| 2.0/8 | 2.0 | 8 | 2692 | 1100 | 460 |
| 2.0/10 | 10 | 2692 | 460 | ||
| 2.0/13 | 13 | 2694 | 505 | ||
| 2.0/16 | 16 | 2698 | 660 | ||
| 2.0/20 | 20 | 2702 | 815 | ||
| 2.0/25 | 25 | 2706 | 998 | ||
| 2.0/40 | 40 | 2719 | 1470 | ||
| 2.5/8 | 2.5 | 8 | 2776 | 1200 | 846 |
| 2.5/10 | 10 | 2778 | 847 | ||
| 2.5/13 | 13 | 2782 | 850 | ||
| 2.5/30 | 30 | 2795 | 856 | ||
| 3.0/8 | 3.0 | 8 | 2807 | 1300 | 521 |
| 3.0/10 | 10 | 2809 | 621 | ||
| 3.0/13 | 13 | 2813 | 787 | ||
| 3.0/16 | 16 | 2817 | 1031 | ||
| 3.0/35 | 35 | 2834 | 1755 | ||
| 3.0/40 | 40 | 2838 | 2243 |
*Silk pressure vessels have been sold all over the country as well as America,Canada,Russian,Mexican,East Asia,AND Africa ect.The diameter of pressure vessel is from 600mm-1800mm. The design temperature of pressure vessel is 150℃.
As an authorized distributor of Silk, we offer some of the highest quality ring-coated storage tanks on the market today. We have gas tanks that can meet any need. If you are not sure which size is right for you, our plant's system experts will advise you and help you determine the gas tanks you need.
