Product Details:
Payment & Shipping Terms:
|
| Type: | Screw | Configuration: | Stationary |
|---|---|---|---|
| Dimension: | 1420×850×1110mm | Power: | 18.5KW |
| Driven Type: | Direct Driven | Pressure: | 8bar |
| Feature1: | High Efficiency And Cost-effective | Feature2: | Enviromental Friendly |
| Feature3: | Safe And Stable Operation System | Feature4: | Low Noise And Environmental Friendly |
| High Light: | screw drive air compressor,rotary screw air compressor |
||
Energy saving LG 2.5/8 15KW 2.5m3/min stationary belt driven screw air compressor with free spare parts
Specification
| Model | LG3/8 |
| Capacity (m³/min) | 3 |
| Working Pressure (Mpa) | 8 |
| Power (kw) | 18.5kw |
| Weight | 600KG |
| Dimension (mm) | 1420×850×1110 |
Air screw compressor :
Specification:
the capacity range:0.58~82M3/min
the working pressure range :0.7~1.3Mpa
the motor power:5.5~450KW
The motor power from 30kw to 450kw Direct driven are available
Advantages of Stationary Screw LG compressor :
1. High efficiency and cost-effective
2. Environmental friendly
3. Superior electric controlling system
4. Safe and stable operation system
5. Low noise
Features:
1. This series of mine air compressor can be used directly in the mine which is full of coal gas or methane gas. It can reduce the length of pipeline aspirated from the ground to the underground, reduce the pressure loss of long pipeline, and reduce the loss of gas because of the leakage of pipeline.
2. Adopts the German GHHRAND air end, which is with advanced configuration. Low fall between the 5:6 proportions of rotors attributes to small loss of circumfluence. The 4:6 proportions of rotors can improve the efficiency by 10% ~12%, and save 25% electric. It owns high precision and has the characteristic of running stability.
3. Adopts the air controlling system manufactured by Austria HOREBIGER Company, stable and reliable.
4. The load adjustment is between 0 and 100, and is able to automatically adjust the consumption of power along with the actual air flow.
5. Safe and reliable of use, and has the functions of explosion-proof, over-loading, short-circuit, electric leakage and so on. It has the protection equipment of giving an alarm when it is of overheat, blockage of air filter, blockage of oil filter and can automatically shutdown when it is overheat. It also has the capacity control, pressure switch and safety valve to avoid over pressure.
About KAISHAN COMPANY:
1- Established in 1990 ,Specialized in this line more than 20 years.
2- National Free-inspection Product
3-Have advanced machining centers, automatic production line shape and heat treatmentequipment etc 500 sets from the United Kingdom, United States, Japan, Germany.
4-Exported to Australia/ Mongolia/ Japan/ South-Africa etc.
Motor driven stationary air compressor Specification.
| Mode | Pressure MPa |
Capacity m3/min |
Power kW |
Dimension mm |
| LG-1.2/8 | 0.8 | 1.2 | 7.5 | 900×700×1040 |
| LG-1.0/10 | 1.0 | 1.0 | ||
| LG-0.8/13 | 1.3 | 0.8 | ||
| LG-1.7/7 | 0.7 | 1.7 | 11 | 1060×800×1230 |
| LG-1.7/8 | 0.8 | 1.7 | ||
| LG-1.5/10 | 1.0 | 1.5 | ||
| LG-1.2/13 | 1.3 | 1.2 | ||
| LG-2.4/7 | 0.7 | 2.4 | 15 | 1060×800×1230 |
| LG-2.4/8 | 0.8 | 2.4 | ||
| LG-2.2/10 | 1.0 | 2.2 | ||
| LG-1.7/13 | 1.3 | 1.7 | ||
| LG-3/8G | 0.8 | 3 | 18.5 | 1420×850×1110 |
| LG-3/7 | 0.7 | 3 | 1080×880×1415 | |
| LG-3/8 | 0.8 | 3 | ||
| LG-2.7/10 | 1.0 | 2.7 | ||
| LG-2.3/13 | 1.3 | 2.3 | ||
| LG-3.6/8G | 0.8 | 3.6 | 22 | 1420×850×1110 |
| LG-3.6/7 | 0.7 | 3.6 | 1080×880×1415 | |
| LG-3.6/8 | 0.8 | 3.6 | ||
| LG-3.2/10 | 1.0 | 3.2 | ||
| LG-5.2/7 | 0.7 | 5.2 | 30 | 1300×1100×1650 |
| LG-5/8 | 0.8 | 5 | ||
| LG-4.5/10 | 1.0 | 4.5 | ||
| LG-3.7/13 | 1.3 | 3.7 | ||
| LG-6.5/7G | 0.7 | 6.5 | 37 | 1630×910×1220 |
| LG-6.2/8G | 0.8 | 6.2 | ||
| LG-6.5/7 | 0.7 | 6.5 | 1300×1100×1650 | |
| LG-6.2/8 | 0.8 | 6.2 | ||
| LG-5.6/10 | 1.0 | 5.6 | ||
| LG-4.8/13 | 1.3 | 4.8 | ||
| LGB-6.0/8 | 0.8 | 6.0 | ||
| LGB-5.6/10 | 1.0 | 5.6 | ||
| LGB-4.8/13 | 1.3 | 4.8 | ||
| LG-7.4/7G | 0.7 | 7.4 | 45 | 1778×1000×1300 |
| LG-7.4/7 | 0.7 | 7.4 | 1300×1100×1650 | |
| LG-7.1/8 | 0.8 | 7.1 | ||
| LG-6.5/10 | 1.0 | 6.5 | ||
| LG-5.6/13 | 1.3 | 5.6 | ||
| LG-10.5/7G | 0.7 | 10.5 | 55 | 1950×1160×1550 |
| LG-10/8G | 0.8 | 10 | ||
| LG-7.5/13G | 1.3 | 7.5 | ||
| LG-8.7/10 | 1.0 | 8.7 | 1620×1230×1670 | |
| LG-7.5/13 | 1.3 | 7.5 | ||
| LGB-10/8 | 0.8 | 10 | 1500X1250X1566 | |
| LGB-8.5/10 | 1.0 | 8.5 | ||
| LG-13/8G | 0.7 | 13 | 75 | 2440×1160×1620 |
| LG-10/10G | 1.0 | 10 | ||
| LG-12/10G | 1.0 | 12 | ||
| LG-10/13 | 1.3 | 10 | 1580X1320X1646 | |
| LGB-13/8 | 0.8 | 13 | ||
| LGB-12/10 | 1.0 | 12 | ||
| LG-16.5/7G | 0.7 | 16.5 | 90 | 2560×1300×1620 |
| LG-16/8G | 0.8 | 16 | ||
| LG-14/10G | 1.0 | 14 | ||
| LG-12/13G | 1.3 | 12 | ||
| LG-20/7G | 0.7 | 20 | 110 | 2760×1340×1710 |
| LG-20/8G | 0.8 | 20 | ||
| LG-16/10G | 1.0 | 16 | ||
| LG-13/13G | 1.3 | 13 | ||
| LG-22/8G | 0.8 | 22 | 132 | 2760×1340×1710 |
| LG-20/10G | 1.0 | 20 | ||
| LG-16/13G | 1.3 | 16 | ||
| LG-28/7G | 0.7 | 28 | 160 | 2860×1510×1810 |
| LG-27/8G | 0.8 | 27 | ||
| LG-23/10G | 1.0 | 23 | ||
| LG-20/13G | 1.3 | 20 | ||
| LG-30/8G | 0.8 | 30 | 185 | 3400×2100×2100 |
| LG-21/13G | 1.3 | 21 | 2860×1510×1810 | |
| LG-35/8G | 0.8 | 35 | 200 | 3400×2100×2100 |
| LG-30/10G | 1.0 | 30 | ||
| LG-27/13G | 1.3 | 27 |
